NVR5216-EI
NVR5216-EI
大華

IPC-HFW2441T-ZS

設備名稱：IPC-HFW2441T-ZS
解析度：4百萬畫素
焦距：2.7 mm–13.5 mm
夜視模式：紅外線
供電方式：POE供電
功能：支援錄音

LINE官方帳號：@wolfstc
企業信箱：[email protected]
IG：沃夫資訊工程
Facebook粉絲專頁：沃夫資訊工程
聖弘集團旗下服務：聖弘集團

全台免費丈量
如需監視器規劃、監視器安裝服務
歡迎洽詢LINE官方帳號
LINE官方帳號：@wolfstc

LINE洽詢服務

監視器規格表參考

類型 槍型 半球型 球型
外觀特徵 長筒狀、突出明顯 圓頂型、造型低調 球體狀、電動旋轉結構
鏡頭角度 固定方向或小角度可調 多數固定，有手動調整款 可電動水平旋轉、垂直仰俯
防破壞能力 中等，可輕易看見與碰觸 高，多數有防破壞罩 高，設計較為堅固
適用場合 戶外、牆面、長距離區域 室內、天花板、電梯口 廣場、停車場、監控範圍廣處
嚇阻程度 明顯可見，具比較強的嚇阻作用 外觀隱蔽，比較低調不明顯 中等偏明顯，帶專業感
價格區間 低到中(視型號) 低到中(視型號) 高
規格表
分類: , ,
商品介紹
Camera
Image Sensor 1/2.9″ CMOS
Max. Resolution 2688 (H) × 1520 (V)
ROM 128 MB
RAM 128 MB
Scanning System Progressive
Electronic Shutter Speed Auto/Manual 1/3 s–1/100,000 s
Min. Illumination 0.006 [email protected] (Color, 30 IRE)
0.0006 [email protected] (B/W, 30 IRE)
0 lux (Illuminator on)
S/N Ratio >56 dB
Illumination Distance Up to 60 m (196.85 ft) (IR LED)
Illuminator On/Off Control Auto; Manual
Illuminator Number 4 (IR LED)
Pan/Tilt/Rotation Range Pan: 0°–360°
Tilt: 0°–90°
Rotation: 0°–360°
Lens
Lens Type Motorized vari-focal
Lens Mount φ14
Focal Length 2.7 mm–13.5 mm
Max. Aperture F1.5
Field of View H: 104°–29°;
V: 54°–16°;
D: 125°–34°
Iris Control Fixed
Close Focus Distance 0.8 m (2.62 ft)
DORI Distance
 Lens Detect Observe Recognize Identify
W 64.0 m (209.97 ft) 25.6 m
(83.99 ft)		 12.8 m
(41.99 ft)		 6.4 m
(20.99 ft)
T 210.0 m (688.97 ft) 84.0 m
(275.59 ft)		 42.0 m
(137.80 ft)		 21.0 m
(68.90 ft)
DORI (Detect, Observe, Recognize, Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances. For intelligent function distances, refer to installation and commissioning manual/project design tool.
Intelligence
IVS (Perimeter Protection) Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human)
Smart Search Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos
Video
Video Compression H.265; H.264; H.264H; H.264B; MJPEG (Only supported by the sub stream)
Smart Codec Smart H.265+; Smart H.264+
Video Frame Rate Main stream: 2688 × 1520@(1–20 fps)/2560 × 1440@(1-25/30 fps)
Sub stream: 704 × 576@(1–25 fps)/704 × 480@(1–30 fps)
*The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity.
Stream Capability 2 streams
Resolution 2688 × 1520 (2688 × 1520); 2560 × 1440 (2560 × 1440); 2304 × 1296 (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)
Bit Rate Control CBR/VBR
Video Bit Rate H.264: 32 kbps–6144 kbps;
H.265: 12 kbps–6144 kbps
Day/Night Auto(ICR)/Color/B/W
BLC Yes
HLC Yes
WDR 120 dB
White Balance Auto; natural; street lamp; outdoor; manual; regional custom
Gain Control Manual;Auto
Noise Reduction 3D NR
Motion Detection OFF/ON (4 areas, rectangular)
Region of Interest (RoI) Yes (4 areas)
Smart Illumination Yes
Image Rotation 0°/90°/180°/270° (Support 90°/270° with 2688 × 1520 resolution and lower)
Mirror Yes
Privacy Masking 4 areas
Audio
Built-in MIC Yes
Audio Compression G.711a; G.711Mu; G.726; PCM
Alarm
Alarm Event No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; audio detection; voltage detection; defocus detection; external alarm (Only – ZAS supports); SMD; security exception
Network
Network Port RJ-45 (10/100 Base-T)
SDK and API Yes
Network Protocol IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; NTP; Multicast; ICMP; IGMP; P2P
Interoperability ONVIF (Profile S/Profile G/Profile T); CGI
User/Host 6 (Total bandwidth: 36 M)
Storage FTP; SFTP; Micro SD card (support max. 256 GB)
Browser IE
Chrome
Firefox
Management Software SmartPSS Lite; DSS; DMSS
Mobile Client iOS; Android
Cyber Security Video encryption; Configuration encryption; Digest; WSSE; Account lockout; Security logs; IP/MAC filtering; Generation and importing of X.509 certification; syslog; HTTPS; 802.1x; Trusted boot; Trusted execution; Trusted upgrade
Certification
Certifications CE-LVD: EN62368-1;
CE-EMC: Electromagnetic Compatibility Directive
2014/30/EU;
FCC: 47 CFR FCC Part 15, Subpart B;
UL/CUL: UL62368-1 & CAN/CSA C22.2 No. 62368-1-14
Port
Audio Input 1 channel (RCA port) (Only – ZAS supports)
Audio Output 1 channel (RCA port) (Only – ZAS supports)
Alarm Input 1 channel in: 5mA 3V–5V DC (Only – ZAS supports)
Alarm Output 1 channel out: 300mA 12V DC (Only – ZAS supports)
Power
Power Supply 12 VDC/PoE (802.3af)
Power Consumption -ZS:
Basic: 2.4 W (12 VDC); 3.1 W (PoE)
Max. (H.265+intelligence on +WDR +IR on): 8.7 W (12 VDC); 10.1 W (PoE)
-ZAS:
Basic: 2.4 W (12 VDC); 3.1 W (PoE)
Max. (H.265+intelligence on +WDR +IR on): 8.8 W (12 VDC); 10.2 W (PoE)
Environment
Operating Temperature –30 °C to +60 °C (–22 °F to +140 °F)
Operating Humidity ≤95%
Storage Temperature –40 °C to +60 °C (–40°F to +140°F)
Protection IP67, IK10 (optional)
Structure
Casing Material Metal
Product Dimensions 238.5 mm × 90.7 mm × 90.7 mm (9.39″ × 3.57″ × 3.57″) (L × W × H)
Net Weight -ZS: 0.73 kg (1.6 lb)
-ZAS: 0.76 kg (1.7 lb)
Gross Weight -ZS: 0.99 kg (2.2 lb)
-ZAS: 1.02 kg (2.2 lb)
